| Battery Chemistry |
LiFePO₄ |
| Capacity |
100 Ah |
| Scalability |
Max 32 pcs in parallel (Max. 64 pcs can parallel with CAN-Bridge) |
| Nominal Voltage |
51.2 V |
| Operating Voltage |
44.8 V – 57.6 V |
| Nominal Energy |
5.12 kWh |
| Charge Current – Max Continuous |
100 A |
| Charge Current – Peak |
120 A (10 sec) |
| Discharge Current – Max Continuous |
120 A |
| Discharge Current – Peak |
150 A (10 sec) |
| Recommended Depth of Discharge |
80% DoD |
| Dimension (W × H × D) (Without hanging board) |
370 × 548 × 140 mm |
| Weight Approximate |
41 kg |
| LED Indicator |
LED (SOC, working, protecting) & Buzzer |
| IP Rating of Enclosure |
IP21 |
| Operating Temperature |
Charge: 0 – 55℃ / Discharge: -20 – 55℃ |
| Storage Temperature |
0 – 35℃ |
| Relative Humidity |
95% (non-condensing) |
| Altitude |
≤3000m |
| Cycle Life |
≥6000 (25℃±2℃, 70% EOL) |
| Installation |
Wall-Mounted, Floor-Mounted, Stack-Mounted |
| Communication |
CAN2.0, RS485, Bluetooth+APP |
| Warranty Period |
5 years |
| Energy Throughput |
8 MWh |
| Certification |
UN38.3, MSDS, CE, CB |
